Combining the LINDY 19" LCD KVM Terminal and U8C Modular KVM Switch this great value bundle gives you the convenience of an LCD Terminal with an easily installed 8 port KVM switch, all in just 1U!

The LINDY Modular KVM LCD Terminal is a great space saver, featuring a high-quality 19" Active Matrix TFT LCD display, notebook style CH keyboard with separate numeric keypad, and touchpad all in just 1U! The complete drawer can be slid in and out of a 19" rack, while the LCD can be slid out separately from the keyboard drawer and flipped up in front of the rack. This allows the cabinet door to be closed and locked leaving the display to remain visible. The LCD Terminal also has a fully featured OSD (On Screen Display), allowing the easy set up and management of the console, and supports resolutions up to 1280 x 1024.

The Modular KVM switch features a modular design offering the ability to add a second console featuring remote access either via an IP remote extension unit or via a remote Cat.5 extender unit. Using this method, system administrators are able to access and administrate their servers and KVM switches from a remote office workstation. The optional access modules can be purchased separately and are simply installed into the back of the U8C Modular KVM Switch.

The U8C KVM has a fully featured OSD (On Screen Display), allowing the easy set up and management of the switch, and supports resolutions up to 1920x1440 using the local console.

This KVM switch incorporates a modular design concept which allows for dual console access. The switch can also be daisy chained with further U8/16 Modular KVM Switches to control up to 128 servers/workstations from 8 daisy chained 16 port KVM switches.

Also available as a 16 Port Bundle

Specifications & Features

LCD Terminal

• 19” 1U Metal drawer with double ball bearing slide rails on each side and modular KVM Switch insertion option
• LCD monitor and keyboard (CH layout) with touchpad on individual drawers, can be slid and used independently on each other
• Key locking mechanism with 2 keys
• 17” 1280 x 1024 with auto-off function when panel is closed, or when no VGA signal is present, > 50,000 hours LCD backlight lifetime
• OSD for screen adjustments with adjustment buttons near the LCD
• Built in touchpad and keyboard with separate numeric keypad, PS/2 & USB switchable
• External power supply, switching type 100-240VAC 50/60Hz, ~40W with IEC input 12VDC ~3.33A regulated with ~1.6m DC cable 5.5/2.5mm DC connector
• Dimensions: 19”/1U, 50cm depth, 19” rack mountable for 57-87cm front/back rail distance

16 Port KVM Switch

• 16 port KVM switch in a 1U, 19” rackmount size design
• Built-in daisy chain port allows daisy chaining of up to 8 LINDY Uor P series KVM switches to support up to 128 computers
• Local console operation plus optional KVM over IP or KVM over Cat.5 control modules
• Remote mass storage device support for KVM over IP access for version U8/16-IP
• Supports all commonly used operating systems
• Support for PC, Mac and Sun computers with USB ports
• Hot Plug Support - add or remove computers and KVM switches for maintenance without powering down the switch or the connected computers
• High Quality Video – Local console supports display resolutions of up to 1920x1440 with cable lengths up to 10m
• No software required for local or Cat.5 KVM access - easy PC selection via On Screen Display Menu, Push Buttons or Keyboard Hot Keys
• Provides various Hotkeys (Scroll-Lock/ Caps-Lock/ Num-Lock/ L-Alt/ L-Ctrl/ L-Win/ R-Alt/ R-Ctrl/ R-Win) for switching computer ports and other control functions
• Integrated password security protection for up to 8 users + admin with access control list restrictions for the users
• Eight character password protection and search function for server name
• Remote IP enterprise security architecture, password protected using encrypted data transmission either via secured web browser session
• Auto Scan Mode for monitoring computers with adjustable scan time from 5~99 seconds
• Keyboard status is automatically restored when switching between computers
• LED Display for easy status monitoring
• Buzzer sound for port switching confirmation
• Uses special single connector USB/PS/2 + VGA KVM cables with 15 Way Hi-Density connectors at the KVM Switch end
• Maintains continuous keyboard and mouse emulation
• Dimensions: 44.5 x 17 x 4.4 cm
